The LM series brings a fresh update to liquid cooling with a compact 2.4" IPS display that now supports MP4 video playback for a more dynamic screen experience. Cooling performance is refined with an upgraded pump for better efficiency and quieter operation.

Technical Spec

Net Weight - 1729 g

Radiator Dimensions - 402×120×27 mm(L×W×H)

Radiator Material - Aluminum

Tube length - 410 mm(L×W×H)

Pump Dimensions - 90×80×63 mm(L×W×H)

Pump Speed - 2500~3400 RPM±10%

Pump Connector - 4-pin PWM

Pump Rated Voltage - 12 VDC

Pump Rated Current - 0.29 A

Pump Power Consumption - 3.48 W

Fan Dimensions - 120×120×25 mm(L×W×H)

Fan Speed - 400~2400 RPM±10%

Fan Airflow - 66.23 CFM

Fan Air Pressure - 3.27 mmAq

Fan Noise ≤36.07 dB(A)

Fan Connector 4-pin PWM

Bearing Type Hydro Bearing

Fan Rated Voltage 12 VDC

Fan Rated Current 0.18 A

Fan Power Consumption 2.16 W

LED Type Addressable RGB LED

LED Connector 3-pin(+5V-D-G)

LED Rated Voltage 5 VDC

LED Power Consumption 1.5 W（PUMP）/ 3.5 W（FAN×3）
