CL6600 rethinks case design for the liquid-cooling era. By physically separating thermal zones and airflow paths, it prevents heat buildup and cross-interference that conventional layouts can’t avoid. It also comes with an advanced 360mm liquid cooler and dual bottom ARGB fans, delivering strong performance and creating a vibrant interior.

Front I/O Ports

- USB3.0×2

- Gen2 Type-C x1

- Audio/Mic×1

3.5" Drive Bays - 2+1

2.5" Drive Bays - 1+1

Expansion Slots - 7 Slots

Pre-Installed Fans - Bottom: 2×120mm ARGB (Reverse Blade)

Fan Support

- Top: 3×120mm/2×140mm

- Front: 2×140mm

- Rear: 1×140/1×120mm

- Bottom: 2×120mm

Radiator Support

- Top: Pre-Installed 360mm

- Front: NA

- Rear: 120mm

CPU Cooler Height Limit - 175mm

GPU Size Limit - 413mm/388mm (With Front Fan)

Power Supply Type - ATX PS2（maximum length: 160mm）/SFX/SFX-L

Radiator Dimensions - 402×120×27 mm

Radiator Material - Aluminum

Tube length - 250 mm

Pump Dimensions - 118×80×76 mm

Pump Speed - 2500~3400 RPM±10%

Pump Connector - 4-pin PWM

Pump Rated Voltage - 12 VDC

Pump Rated Current - 0.29 A

Pump Power Consumption - 3.48 W

Fan Dimensions - 120×120×25 mm

Fan Speed - 500~2500 RPM±10%

0 rpm<5 % PWM

Fan Airflow - 73.41 CFM

Fan Air Pressure - 4.69 mmAq

Fan Noise - ≤35.63 dB(A)

Fan Connector - 4-pin PWM

Bearing Type - Fluid Dynamic Bearing

Fan Rated Voltage - 12 VDC

Fan Rated Current - 0.3 A

Fan Power Consumption - 3.6 W

LED Type - Addressable RGB LED

LED Connector - 3-pin(+5V-D-G)

LED Rated Voltage - 5 VDC

LED Power Consumption - 1.7 W（PUMP）
