Powerful cooling performance, air-cooled ceiling; 3℃+ performance improvement over the third generation, 100% avoid RAM, with incomparable super compatibility; Quick installation, magnetic top cover + unique fan snap-on structure design; Reserve the third fan position and distribute the installation accessories; Unique matrix fin brand family design; Luminous LOGO, light and dark effects can be switched in the dual mode state;

Application For

Intel - LGA2066/2011-v3/2011/1700/1200/1151/1150/1155

AMD - AM5/AM4

Technical Spec

Product Dimensions - 144×147×164 mm(L×W×H)

Heatsink Dimensions - 140×110×160 mm(L×W×H)

Net Weight - 1575 g

Heatpipe - Ø6 mm×7 pcs

Fan Dimensions - 140×140×25 mm(L×W×H) / 120×120×25 mm(L×W×H)

Fan Speed (Performance Mode) - 500~1700 RPM±10%

Fan Airflow (Performance Mode) - 79.1 CFM / 58.06 CFM

Fan Air Pressure (Performance Mode) - 2.44 mmAq / 2.1 mmAq

Overall Noise (Performance Mode) - ≤29.3 dB(A)

Fan Speed (Quiet Mode) - 500~1350 RPM±10%

Fan Airflow (Quiet Mode) - 63.76 CFM / 46.75 CFM

Fan Air Pressure (Quiet Mode) - 1.58 mmAq / 1.35 mmAq

Overall Noise (Quiet Mode) - ≤22.6 dB(A)

Fan Connector - 4-pin PWM

Bearing Type - Fluid Dynamic Bearing

Motor Type - 6-Pole Fan Motor

Fan Rated Voltage - 12 VDC

Fan Rated Current - 0.1 A / 0.07 A

Fan Power Consumption - 1.2 W / 0.84 W

Rated Voltage - 12 VDC

Power Consumption (Performance Mode) - 2.88 W

Power Consumption (Quiet Mode) - 1.56 W
