Application For
Technical Spec
Product Dimensions - 126×98×157 mm(L×W×H)
Heatsink Dimensions - 124×76×151 mm(L×W×H)
Net Weight - 1252 g
Heatpipe - Ø6 mm×7 pcs
Fan Dimensions - 120×120×25 mm(L×W×H)
Fan Speed - 2700±10% RPM (max)
Fan Airflow - 77.23 CFM
Fan Air Pressure - 5.13 mmAq
Fan Noise - 21.0/28.8/36.0 dB(A)
Fan Connector - 4-pin PWM
Bearing Type - Hydro Bearing
Fan Rated Voltage - 12 VDC
Fan Rated Current - 0.35 A
Fan Power Consumption - 4.2 W
Display Module Rated Current - 0.13 A±10%
Display Module Rated Voltage - 5 VDC
Display Module Power Consumption - 0.65 W
Display Area - 29x39 mm
